○指导下的操作使调试变得简便、省时且安全
○广泛的诊断方法可以使运行免于维护且设备的可用性达到很高水平
○可以剪短的探针使标准化简便易行,且在规划上具有最高度的灵活性
○指导下的操作使调试变得简便、省时且安全
○广泛的诊断方法可以使运行免于维护且设备的可用性达到很高水平
○可以剪短的探针使标准化简便易行,且在规划上具有最高度的灵活性
量程 - 距离 | 75m |
过程温度 | -196 ... 450 °C |
过程压力 | -1 ... 400 bar |
测量精度 | ± 2 mm |
型式 | Coax version ø 21.3 mm with multiple hole Coax version ø 42.2 mm with single hole Coax version ø 42.2 mm with multiple hole Exchangeable rod ø 16 mm Exchangeable cable ø 2 mm with gravity weight Exchangeable cable ø 4 mm with gravity weight Exchangeable cable ø 2 mm with centering weight Exchangeable cable ø 4 mm with centering weight |
接液材质 | 316L 镍基热强合金 C22 316
|
螺纹连接 | ≥ G¾, ≥ ¾ NPT |
法兰连接 | ≥ DN25, ≥ 1" |
密封材料 | FFKM graphit and ceramic
|
外壳材料 | 塑料 铝Aluminium 不锈钢,精密铸件 不锈钢,经电解抛光 |
保护方式 | IP 66/IP 68 (0.2 bar) IP 66/IP 67 IP 66/IP 68 (1 bar) |
输出 | Profibus PA Foundation Fieldbus 4 … 20 mA/HART - two-wire Modbus 4 … 20 mA/HART - four-wire |
环境温度 | -40 ... 80 °C |
量程 - 距离 | 75m |
过程温度 | -196 ... 450 °C |
过程压力 | -1 ... 400 bar |
测量精度 | ± 2 mm |
型式 | Coax version ø 21.3 mm with multiple hole Coax version ø 42.2 mm with single hole Coax version ø 42.2 mm with multiple hole Exchangeable rod ø 16 mm Exchangeable cable ø 2 mm with gravity weight Exchangeable cable ø 4 mm with gravity weight Exchangeable cable ø 2 mm with centering weight Exchangeable cable ø 4 mm with centering weight |
接液材质 | 316L 镍基热强合金 C22 316
|
螺纹连接 | ≥ G¾, ≥ ¾ NPT |
法兰连接 | ≥ DN25, ≥ 1" |
密封材料 | FFKM graphit and ceramic
|
外壳材料 | 塑料 铝Aluminium 不锈钢,精密铸件 不锈钢,经电解抛光 |
保护方式 | IP 66/IP 68 (0.2 bar) IP 66/IP 67 IP 66/IP 68 (1 bar) |
输出 | Profibus PA Foundation Fieldbus 4 … 20 mA/HART - two-wire Modbus 4 … 20 mA/HART - four-wire |
环境温度 | -40 ... 80 °C |
